A data set of 113 galaxies was presented by Zsolt Frei, Puragra
Guhathakurta, and James E. Gunn at Princeton University and J. Anthony
Tyson at AT&T Bell Laboratories (1996). The galaxies were chosen to
span the Hubble classification classes. All the galaxies in the set
are nearby, well resolved and bright with the faintest having the
total magnitude BT of 12.90. The sample was chosen to be
suitable to test automatic galaxy classification techniques with the
idea that automatic methods of classifying galaxies are necessary to
handle the huge amount of data that will soon be available from large
survey projects, such as the Sloan Digital Sky Survey. All the
images of the set were recorded with charge coupled devices (CCDs) at
the Palomar Observatory with the 1.5 meter telescope and at the
Lowell Observatory with the 1.1 meter telescope. The images were
stored in FITS (Flexible Image Transport System) format with
important data on these galaxies published in the Third Reference
Catalog of Bright Galaxies (de Vaucouleurs et al., 1991). Table
3 shows the number of spiral and elliptical galaxies observed at both
of the observatories along with the broad band pass wavelengths of
the filters through which they were observed.
Table 3:
Data set
Observatory |
Spiral Galaxies |
Elliptical Galaxies |
Bands (nanometer) |
Palomar |
31 |
0 |
500, 650 and 820 |
Lowell |
58 |
14 |
450 and 650 |
The images were processed to a point where the flat field and bias
corrections were made and stars were removed from them. It can be
seen from Figures 4 through 6, which contain scaled down versions of
the all the images from the catalog, that the collection contains a
wide range of galaxy classes.
Figure 4:
Data Set: NGC 2403 to NGC 4242
|
Figure 5:
Data Set: NGC 4254 to NGC 5248
|
Figure 6:
Data Set: NGC 5322 to NGC 6503
|
